Model Name

FA507NV-R77B46CS1

Marketing Name

ASUS TUF Gaming A15

Color

Mecha Gray

Dimension (W x D x H)

35.4 x 25.1 x 2.24 ~ 2.49 cm (13.94″ x 9.88″ x 0.88″ ~ 0.98″)

Weight

2.20 Kg (4.85 lbs)

Processor

AMD Ryzen™ 7 7735HS Mobile Processor (8-core/16-thread, 16MB L3 cache, up to 4.7 GHz max boost)

Chipset

N/A

Discrete/Optimus

MUX Switch + NVIDIA® Advanced Optimus

Graphic

NVIDIA® GeForce RTX™ 4060 Laptop GPU

Graphic Wattage

2420MHz* at 140W (2370MHz Boost Clock+50MHz OC, 115W+25W Dynamic Boost)

Graphic Memory

8GB GDDR6

IGPU

AMD Radeon™ Navi2 Graphics

Panel Size

15.6-inch

Resolution

FHD (1920 x 1080) 16:9

Refresh Rate

144Hz

Viewing Angle

170

Panel Tech

Value IPS-level

Brightness

250nits

Contrast

1000:1

NTSC %

72%

SRGB %

100%

Adobe %

75.35%

Anti glare

Anti-glare display

Adaptive-Sync technology

G-Sync

Pantone

N/A

Support Dolby Vision HDR

N/A

On board memory

N/A

DIMM Memory

8GB DDR5-4800 SO-DIMM *2

Total System Memory

DDR5 16GB

Memory Slot

2x SO-DIMM slots

Memory Max.

32GB

Multi-channel memory technology

Support dual channel memory

How to upgrade memory

Upgradable

System Storage Installed

512GB PCIe® 4.0 NVMe™ M.2 SSD

M.2 slots support either SATA or NVMe

2

M.2 SSD Support List

M.2 PCIe 512GB

M.2 PCIe 1TB

M.2 PCIe 2TB

Expansion Slot (includes used)

2x DDR5 SO-DIMM slots

LAN

10/100/1000 Mbps

Wi-Fi/Bluetooth

Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.)

I/O Ports

1x RJ45 LAN port
1x Type C USB 4 support DisplayPort™
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery / G-SYNC
2x USB 3.2 Gen 1 Type-A

Display output

1x HDMI 2.1 FRL

Audio

1x 3.5mm Combo Audio Jack

Webcam

720P HD camera

Mic

Built-in array microphone

Keyboard Type

Backlit Chiclet Keyboard 1-Zone RGB

NumberPad

N/A

Aura Sync

N/A

Speakers

2-speaker system

Audio Tech

AI noise-canceling technology
Dolby Atmos
Hi-Res certification
Support Microsoft Cortana near field/Far field

Operating System

No preinstalled OS

Security

BIOS Administrator Password and User Password Protection
Kensington Security Slot™
Trusted Platform Module (Firmware TPM)

Battery

90WHrs, 4S1P, 4-cell Li-ion

Fast charging

Recharge from 0-50% in 30 minutes

Power

ø6.0, 240W AC Adapter, Output: 20V DC, 12A, 240W, Input: 100~240C AC 50/60Hz universal

Reparability Index (for FR)

8.6
