Marketing Name

ROG Zephyrus G16

Operating System

Windows 11 Home

Office

1-month trial for new Microsoft 365 customers. Credit card required.

Color

Eclipse Gray

Dimension (W x D x H)

35.4 x 24.6 x 1.49 ~ 1.64 cm (13.94" x 9.69" x 0.59" ~ 0.65")

Weight

1.85 Kg (4.08 lbs)

Processor

Intel® Core™ Ultra 9 Processor 285H 2.9 GHz (24MB Cache, up to 5.4 GHz, 16 cores, 16 Threads); Intel® AI Boost NPU up to 13TOPS

Chipset

N/A

Intergrated GPU

Intel® Arc™ Graphics

Discrete/Optimus

MUX Switch + NVIDIA® Advanced Optimus

Graphic

NVIDIA® GeForce RTX™ 5070 Laptop GPU

Graphic Wattage

ROG Boost: 1595MHz* at 105W (1545MHz Boost Clock+50MHz OC, 90W+15W Dynamic Boost)

Graphic Memory

8GB GDDR7

Neural Processor

Intel® AI Boost NPU up to 13TOPS

Panel Size

16-inch

Resolution

2.5K (2560 x 1600, WQXGA) OLED 16:10 aspect ratio

Refresh Rate

240Hz

Viewing Angle

89/89/89/89

Panel Tech

OLED

Brightness

500 nits (Peak)

Contrast Ratio

1,000,000:1

DCI-P3 %

100%

Glare

Glossy display

Adaptive-Sync technology

G-Sync

Pantone

Pantone Validated

Nebula Display

ROG Nebula Display

Support Dolby Vision HDR

Yes

On board memory

32GB LPDDR5X 7467 on board(Actual memory speeds may vary by CPU configuration.)

Total System Memory

LPDDR5X 32GB

Memory Slot

No expansion possible

Memory Max.

32GB

Multi-channel memory technology

Support dual channel memory technology

Storage

2TB PCIe® 4.0 NVMe™ M.2 SSD

M.2 slots support either SATA or NVMe

2

M.2 SSD Support List

1TB M.2 NVMe™ PCIe® G4x4 Performance SSD (ACC/TW only)

2TB M.2 NVMe™ PCIe® G4x4 Performance SSD  (ACC/TW only)

1TB M.2 NVMe™ PCIe® G4x4 Value SSD

2TB M.2 NVMe™ PCIe® G4x4 Value SSD

Expansion Slot (includes used)

2x M.2 PCIe

LAN

N/A

Wireless

Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card (*Bluetooth® version may change with OS version different.)

I/O Ports

1x Thunderbolt™ 4 with support for DisplayPort™ / power delivery (data speed up to 40Gbps)
1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ / power delivery / G-SYNC (data speed up to 10Gbps)
2x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps)
1x card reader (SD) (UHS-II, 312MB/s)

Display output

1x HDMI 2.1 FRL

Camera

1080P FHD IR Camera for Windows Hello

Mic

Built-in 3-microphone array

Keyboard Type

Backlit Chiclet Keyboard 1-Zone RGB

Aura Sync

Yes

Touchpad

Touchpad
N/A

Speakers

4-speaker (dual-force woofer) system with Smart Amplifier Technology, 2 Tweeters

Audio

1x 3.5mm Combo Audio Jack
Built-in 3-microphone array

Audio Tech

AI noise-canceling technology
Dolby Atmos
Hi-Res certification (for headphone)
Smart Amp Technology

Security

BIOS Administrator Password and User Password Protection
Trusted Platform Module (Firmware TPM)

Antivirus

McAfee® 30 days free trial

Battery

90WHrs, 4S1P, 4-cell Li-ion

Fast charging

Recharge from 0-50% in 30 minutes

Power

Rectangle Conn, 200W AC Adapter, Output: 20V DC, 10A, 200W, Input: 100-240V AC, 50/60Hz universal

Required charging power

Min: 45%W
Max: 100%W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Xbox Game Pass

Xbox Game Pass for PC_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)
