Marketing Name

ASUS TUF Gaming F16

Operating System

No preinstalled OS

Color

Jaeger Gray

Dimension (W x D x H)

35.4 x 26.9 x 1.79 ~ 2.73 cm (13.94" x 10.59" x 0.70" ~ 1.07")

Weight

2.20 Kg (4.85 lbs)

Processor

Intel® Core™ i7 Processor 14650HX 2.2 GHz (30MB Cache, up to 5.2 GHz, 16 cores, 24 Threads)

Chipset

Mobile Intel® HM770 Express Chipsets

Intergrated GPU

Intel® UHD Graphics

Discrete/Optimus

MUX Switch + NVIDIA® Advanced Optimus

Graphic

NVIDIA® GeForce RTX™ 5070 Laptop GPU

Graphic Wattage

115W (100W+15W)

Graphic Memory

8GB GDDR7

Panel Size

16-inch

Resolution

2.5K (2560 x 1600, WQXGA) 16:10 aspect ratio

Refresh Rate

165Hz

Viewing Angle

85/85/85/85

Panel Tech

IPS-level

Brightness

400

Contrast Ratio

1000:1

NTSC %

72.00%

SRGB %

100.00%

Adobe %

75.35%

Glare

Anti-glare display

Adaptive-Sync technology

G-Sync

Pantone

N/A

Support Dolby Vision HDR

N/A

On board memory

N/A

DIMM Memory

16GB DDR5-5600 SO-DIMM, the memory speed of the systems vary by CPU SPEC *2

Total System Memory

DDR5 32GB

Memory Slot

2x SO-DIMM slots

Memory Max.

64GB

Multi-channel memory technology

Support dual channel memory technology

Storage

1TB PCIe® 4.0 NVMe™ M.2 SSD

M.2 slots support either SATA or NVMe

2

M.2 SSD Support List

M.2 512GB PCIe SSD

M.2 1TB PCIe SSD

M.2 2TB PCIe SSD

Expansion Slot (includes used)

2x DDR5 SO-DIMM slots
2x M.2 PCIe

LAN

10/100/1000 Mbps

Wireless

Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.)

I/O Ports

1x RJ45 LAN port
1x Thunderbolt™ 4 with support for DisplayPort™ / G-SYNC (data speed up to 40Gbps)
1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ / power delivery (data speed up to 10Gbps)
3x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps)

Display output

1x HDMI 2.1 FRL

Camera

1080P FHD IR Camera for Windows Hello

Mic

Built-in array microphone

Keyboard Type

Backlit Chiclet Keyboard 1-Zone RGB
With Copilot key

*Copilot in Windows (in preview) is rolling out gradually within the latest update to Windows 11 in select global markets. Timing of availability varies by device and market. Learn more: https://www.microsoft.com/en-us/windows/copilot-ai-features?r=1#faq

Aura Sync

Yes

Touchpad

Touchpad
N/A

Speakers

2-speaker system

Audio

1x 3.5mm Combo Audio Jack
Built-in array microphone

Audio Tech

AI noise-canceling technology
Dolby Atmos
Hi-Res certification (for headphone)
Support Microsoft Cortana near field/far field (Microsoft service suspended in spring of 2023.)

Security

BIOS Administrator Password and User Password Protection
Trusted Platform Module (Firmware TPM)

Battery

90WHrs, 4S1P, 4-cell Li-ion

Power

Rectangle Conn, 280W AC Adapter, Output: 20V DC, 14A, 280W, Input: 100-240V AC, 50/60Hz universal

Required charging power

Min: 45W
Max: 100W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.
